Audley 9060-3 Pro 3D Logo UV Printer | 4-Head UV Flatbed with Multi-Layer 3D Printing
Audley UV 3D logo printing is a revolutionary solution for modern fashion brands seeking to elevate their garment branding. Using advanced flatbed UV printing technology, multi-layered ink achieves vivid colors, textured finishes, and raised effects on a variety of substrates, from PET films to leather patches.
Multi-Layer 3D UV Printing Technology
The 9060-3 Pro uses a specialized multi-pass ink layering process to build up physical texture and raised relief directly on the substrate surface. By printing multiple passes of white ink as a base, followed by CMYK color layers, and finishing with varnish or glue, the printer creates tactile, three-dimensional effects that cannot be replicated by standard single-pass UV printing. This capability is particularly valuable for fashion labels, luxury packaging, leather goods, and premium promotional products.
See It In Action
Equipment Gallery
Four-head industrial UV flatbed construction with water-chilled LED curing, white and varnish ink supply, integrated control panel, adjustable height table, and capping station for precision multi-layer 3D logo printing.
Technical Specifications
| Model | 9060-3 (Pro) |
|---|---|
| Printheads | 4x Epson i3200-U1 |
| Max Print Width | 900 mm (35.4 in) |
| Max Print Height | 280 mm (11 in) |
| Printing Resolution | Max 3200 dpi |
| Ink System | CMYK + W + Varnish / Glue + CMYK + W + Varnish |
| Suction Platform | Equipped (vacuum hold-down) |
| Printing Materials | Metal, leather, wood, plastic, glass, ceramic, PET film, and more |
|---|---|
| RIP Software | Photoprint |
| Power | 2500W |
| Package Size | 226 x 152 x 88 cm (89 x 59.8 x 34.6 in) |
| Weight | 380 KG machine / 441 KG crated (840 / 972 lbs) |
| Warranty | 1 year |
PC System Requirements
Multi-layer 3D UV printing requires a high-performance workstation to manage complex RIP calculations and multi-pass print queues simultaneously.
| Processor | Intel Core i9-12900K 3.1 GHz (Turbo 5.1 GHz) | 16 Cores / 24 Threads |
|---|---|
| Memory | 128GB G.SKILL Royal DDR4 3600 (32GB x 4) |
| Graphics | ASUS TUF-GTX1650-04GD6-P-GAMING |
| Motherboard | Asus PRIME Z690-P D4 Desktop Motherboard |
| Primary Storage | Samsung PM9A1 512GB M.2 PCIe 4.0 SSD |
| Secondary Storage | Western Digital Blue 2TB 7200 rpm 256MB SATA3 (WD20EZBX) |
| Network Card | Intel I350-AM4 PCIe x4 Gigabit server network card (industrial camera / machine vision) |
